| รุ่น | EP-H8K5S-48L-NG | EP-H11KS-48L-NG | |||
| Capacity | 8.5KVA/8.5KW | 11KVA/11KW | |||
| Maximum PV Input Power | 10 กิโลวัตต์ | 11KW | |||
| Parallel Capability | NO | NO | |||
| Lithium Battery Activation | YES(By PV or Utility) | ||||
| Lithium Battery Communication | YES(RS485) | ||||
| INPUT | |||||
| แรงดันไฟฟ้าที่กำหนด | 230VAC | ||||
| Acceptable Voltage Range | 170-280VAC(For personal Computer);90-280VAC(For Home Appliances) | ||||
| Frequency | 50/60 Hz(Auto sensing) | ||||
| OUTPUT | |||||
| แรงดันไฟฟ้าที่กำหนด | 220/230/240VAC | ||||
| Surge Power | 17000VA | 22000VA | |||
| Frequency | 50/60 Hz | ||||
| Pure Sine wave | |||||
| Dual Outputs | YES | ||||
| 10ms(For personal Computer);20ms(For Home Appliances) | |||||
| Peak Efficiency | 94% | ||||
| Overload Protection | 5s@>=140%load;10s@110%~140%load | ||||
| Admissible Power Factor | 0.6~1(inductive or capacitive) | ||||
| BATTERY | |||||
| Battery Voltage | 48Vdc | 48Vdc | |||
| Maximum Discharge Current | 180A | 220A | |||
| Floating Charge Voltage | 54Vdc | 54Vdc | |||
| OverCharge Protection | 63Vdc | 63Vdc | |||
| Charging Method | CC/CV | ||||
| SOLAR CHARGER &AC CHARGER | |||||
| Solar Charger TYPE | MPPT | MPPT | |||
| Max.PV Array Power | 5000W*2 | 5000W*2 | |||
| Max.PV Array Open Circuit Voltage | 500Vdc | 500Vdc | |||
| PV Array MPPT Voltage Range | 60Vdc~500Vdc | 60Vdc~500Vdc | |||
| Max.Solar Input Current | 18A*2 | 18A*2 | |||
| Max.Solar Charge Current | 140A | 160 เอ | |||
| Max.AC Charge Current | 120A | 120A | |||
| Max.Charge Current | 140A | 160 เอ | |||
| PHYSICAL | |||||
| Dimensions,DxWxH(mm) | 540x403x122 | ||||
| Package Dimensions,D×W×H(mm) | 637x495x214 | 637×495×214 | |||
| Net Weight(Kgs) | 14.5 | 14.8 | |||
| Communication Interface | RS232/RS485/DRY CONTACT | ||||
| LCD | Colorful Screen+RGB Light | ||||
| ENVIRONMENT | |||||
| ช่วงอุณหภูมิในการทำงาน | -10℃ to 55℃ | ||||
| Storage temperature | -15℃~60℃ | ||||
| ความชื้น | 5%to 95%Relative Humidity(Non-condensing) | ||||
