| MODEL | EP-H8K5S-48L-NG | EP-H11KS-48L-NG | ||
| Capacity | 8.5KVA/8.5KW | 11KVA/11KW | ||
| Maximum PV Input Power | 10KW | 11KW | ||
| Parallel Capability | NO | NO | ||
| Lithium Battery Activation | YES(By PV or Utility) | |||
| Lithium Battery Communication | YES(RS485) | |||
| INPUT | ||||
| Nominal Voltage | 230VAC | |||
| Acceptable Voltage Range | 170-280VAC(For personal Computer);90-280VAC(For Home Appliances) | |||
| Frequency | 50/60 Hz(Auto sensing) | |||
| OUTPUT | ||||
| Nominal Voltage | 220/230/240VAC | |||
| Surge Power | 17000VA | 22000VA | ||
| Frequency | 50/60 Hz | |||
| Waveform | Pure Sine wave | |||
| Dual Outputs | YES | |||
| Transfer Time | 10ms(For personal Computer);20ms(For Home Appliances) | |||
| Peak Efficiency | 94% | |||
| Overload Protection | 5s@>=140%load;10s@110%~140%load | |||
| Admissible Power Factor | 0.6~1(inductive or capacitive) | |||
| BATTERY | ||||
| Battery Voltage | 48Vdc | 48Vdc | ||
| Maximum Discharge Current | 180A | 220A | ||
| Floating Charge Voltage | 54Vdc | 54Vdc | ||
| OverCharge Protection | 63Vdc | 63Vdc | ||
| Charging Method | CC/CV | |||
| SOLAR CHARGER &AC CHARGER | ||||
| Solar Charger TYPE | MPPT | MPPT | ||
| Max.PV Array Power | 5000W*2 | 5000W*2 | ||
| Max.PV Array Open Circuit Voltage | 500Vdc | 500Vdc | ||
| PV Array MPPT Voltage Range | 60Vdc~500Vdc | 60Vdc~500Vdc | ||
| Max.Solar Input Current | 18A*2 | 18A*2 | ||
| Max.Solar Charge Current | 140A | 160A | ||
| Max.AC Charge Current | 120A | 120A | ||
| Max.Charge Current | 140A | 160A | ||
| PHYSICAL | ||||
| Dimensions,DxWxH(mm) | 540x403x122 | 540x403x122 | ||
| Package Dimensions,D×W×H(mm) | 637x495x214 | 637x495x214 | ||
| Net Weight(Kgs) | 14.5 | 14.8 | ||
| Communication Interface | RS232/RS485/DRY CONTACT | |||
| LCD | Colorful Screen+RGB Light | |||
| ENVIRONMENT | ||||
| Operating Temperature Range | -10℃ to 55℃ | |||
| Storage temperature | -15℃~60℃ | |||
| Humidity | 5%to 95%Relative Humidity(Non-condensing) | |||
