Technical specification

Model EP-FS016A1
Total Energy 16.08kWh
Usable Enegy(DC)* 15.27kWh
Voltage 44.8~57.6Vdc
Nominal Voltage 51.2Vdc
Rated Capacity 314Ah
Max.Charge Voltage 57.6Vdc
Max.Charging Current 150A
Max.Charging Power 7680W
Max.Dischaging Current 200A
Max.Discharging Power 10240W
Short Current 540A
Max.recommended DOD 95%
Weight 135kg
Dimension(mm)(H*L*W) 871*450*250mm
Installation floor stand
Cell Technology LiFePO4,Lithum Iron Phoshate
Cycle Life 6000 Cydes@90%DOD,25℃/0.5C,60%EOL
Operating Condition:
Operating Charge 0~55℃
Temperature Discharge 0~55℃
Standard Ambient Temperature Range 0~40℃
Storage Temperature Range >1 month 0~35℃/≤1 month -20~45℃
Humidity 5%~95%(RH)(No Condensation)
Cooling Type Natural cooling
Case Material Metal
IP Rating IP20
Protective Class I
Scalability Max.25 batteries in Parallel
Communication CAN/RS485
Battery Protection Over-current/Over-voltage/Short circuit/Under-voltage/Over-temperature
Certificates CE,UN38.3,MSDS
Warranty 5years
