| Lithium battery Communication | YES(RS485) |
| INPUT | |
| Nominal Voltage | 230VAC |
| Acceptable Voltage Range | 170-280VAC(For personal Computer);90-280vac(For Home Appliances) |
| Frequency | 50/60 Hz(Auto sensing) |
| OUTPUT | |
| Nominal Voltage | 220/230VAC±5% |
| Surge Power | 12400VA |
| Frequency | 50/60Hz |
| Waveform | Pure Sine wave |
| Transfer Time | 10ms(For personal Computer);20ms(For Home Appliances) |
| Peak Efficiency | 94% |
| Overload Protection | 5s@>=140%load;10s@110%~140%load |
| Crest Factor | 3:1 |
| Admissible Power Factor | 0.6~1(inductive or capacitive) |
| BATTERY | |
| Battery Voltage | 48Vdc |
| Floating Charge Voltage | 54Vdc |
| OverCharge Protection | 63Vdc |
| Charging Method | CC/CV |
| SOLAR CHARGER&AC CHARGER | |
| Solar Charger Type | MPPT |
| Max.PV Array Power | 6500W |
| Max.PV Array Open Circuit Voltage | 500Vdc |
| PV Array MPPT Voltage Range | 60Vdc~500Vdc |
| Max.Solar Input Current | 27A |
| Max.Solar Charge Current | 120A |
| Max.AC Charge Current | 80A |
| Max.Charge Current | 120A |
| PHYSICAL | |
| Dimensions,D×W×H(mm) 450*300*130 | |
| Package Dimensions,D×W×H(mm) | 540x390x210 |
| Net Weight(Kg) 12 | |
| Communication Interface | RS232/RS485 |
| ENVIRONMENT | |
| Operating Temperature Range | (-10℃ to 50℃) |
| Storage Temperature | (-15℃~50℃) |
| Humidity | 5%to 95%Relative Humidity(Non-condensing) |
