| MODEL | EP-H1K5S-24L-NG | EP-H2K5S-24L-NG | EP-H3K5S-24L-NG | ||
| Capacity | 1.5KVA/1.5KW | 2.5KVA/2.5KW | 3.5KVA/3.5KW | ||
| Parallel Capability | NO | NO | NO | ||
| Lithium Battery activation | YES(By PV only) YES(By PV or Utility) | ||||
| Lithium Battery communication | YES(RS485) | ||||
| Built-in WIFl | Optional | ||||
| INPUT | |||||
| Nominal Voltage | 230VAC | ||||
| Acceptable Voltage Range | 170-280VAC(For personal Computer);90-280vac(For Home Appliances) | ||||
| Frequency | 50/60 Hz(Auto sensing) | ||||
| OUTPUT | |||||
| Nominal Voltage | 220/230VAC±5% | ||||
| Surge Power | 3000VA | 5000VA | 7000VA | ||
| Frequency | 50/60Hz | ||||
| Waveform | Pure Sine wave | ||||
| Transfer Time | 10ms(For personal Computer);20ms(For Home Appliances) | ||||
| Peak Efficiency(PV to INV) | 96% | ||||
| Peak Efficiency(Battery to INV) | 93% | ||||
| Overload Protection | 5s@>=140%load;10s@110%~140%load | ||||
| Crest Factor | 3:1 | ||||
| Admissible Power Factor | 0.6~1(inductive or capacitive) | ||||
| BATTERY | |||||
| Battery Voltage | 24Vdc | 24Vdc | 24Vdc | ||
| Floating Charge Voltage | 27Vdc | 27Vdc | 27Vdc | ||
| OverCharge Protection | 33Vdc | 33Vdc | 33Vdc | ||
| Charging Method CC/CV | |||||
| SOLAR CHARGER&AC CHARGER | |||||
| Solar Charger Type | MPPT | ||||
| Max.PV Array Power | 2000W | 3000W | 4000W | ||
| Max.PV Array Open Circuit Voltage | 500VDC | ||||
| PV Array MPPT Voltage Range 60VDC~500VDC | |||||
| Max.Solar Input Current | 15A | 15A | 15A | ||
| Max.Solar Charge Current 60A 100A 100A | |||||
| Max.AC Charge Current | 60A | 60A | 80A | ||
| Max.Charge Current(PV+AC) | 60A | 100A | 100A | ||
| PHYSICAL | |||||
| Dimensions,D×WxH(mm) | 358*295*100 | 358*295*100 | 358*295*100 | ||
| Package Dimensions,D×W×H(mm) 465*380*175 465*380*175 465*380*175 | |||||
| Net Weight(Kg) | 6 | 6.5 | 7 | ||
| Communication Interface RS232+RS485 | |||||
| ENVIRONMENT | |||||
| Operating Temperature Range | (-10℃ to 55℃) | ||||
| Storage Temperature | (-15℃~60℃) | ||||
| Humidity | 5%to 95%Relative Humidity(Non-condensing) | ||||
| Ingress Protection | IP21 | ||||
